| Specifications |
 |
| Travel range
|
|
|
|
| (X / Y / Z), mm | | ±25.0 / ±25.0 / ±15.0
|
|
|
|
| (θx / θY / θz), deg | | ±15.0 / ±15.0 / ±30.0
|
|
|
|
| Accuracy
|
|
|
|
| (X / Y / Z), μm | | On request
|
|
|
|
| (θx / θY / θz), μrad | | ±300 / ±300 / ±300
|
|
|
|
| Repeatability
|
|
|
|
| (X / Y / Z), μm | | ±0.51 / ±0.12 / ±0.06
|
|
|
|
| (θx / θY / θz), μrad | | ±1.00 / ±1.00 / ±1.00
|
|
|
|
| Load Capacity, kg | | ≤30.00 |
|
|
|
|
|
|
|
Product added to the Wishlist
| Ordering Information |
|
| Model |
|
Description |
|
|
|
Qty. |
|
|
|
|
| 8HEX280 |
|
6DOF Platform |
|
|
|
|
|
|
|
| 8UMC-02-6 |
|
6DOF Platform Controller |
|
|
|
|
|
|
|
|
|
